Easy Integration – Works with any air-powered dental unit via 4-hole tubing; compatible with existing foot control.
Precision Torque Control – Maintains constant speed under varying pressure for better handling.
Bright Illumination – Built-in motor LED (32,000 lux), compatible with fiber optic handpieces.
Touchscreen Panel – Simplifies operation.
Digital Speed Display – Easy to monitor and adjust speed.
Three Gear Ratios – 1:1, 16:1, and 1:5 settings available.
E-Type Coupling – Universal motor connection.
|
Product name |
Dental Electric Motor |
|
Model |
NL400-2 |
|
Certificate |
ISO, CE |
|
Function |
Forward/Reverse |
|
Rotation |
100-20,0000rpm/min |
|
Bur applicable |
1.59-1.6 mm Diameter |
|
Input power |
100-240V 1.6A |
|
Frequency |
50 / 60 Hz |
|
Output power |
24V 5A |
|
Dimension(mm) |
135*140*60 |
|
Weight |
357g |
Structure and Components:
Host: 1pc
Motor: 1pc
Handle tube: 1pc
